X-T20 – FujiDB

Quick Specs

Effective pixels24.3 megapixels

Sensor size23.6 × 15.6 mm

Sensor typeCMOS

ProcessorX-Processor Pro2

Focal length multiplier1.5×

Lens mountFujifilm X

Viewfinder typeElectronic

Viewfinder resolution2.36 MP

Viewfinder coverage100%

Viewfinder magnification0.93×

Articulated LCDTilting

Battery descriptionNP-W126s lithium-ion battery

Battery life (CIPA)350

Weight (inc. batteries)383 g

Film Simulations

15 modes

PROVIA/StandardVelvia/VividASTIA/SoftClassic ChromePRO Neg.HiPRO Neg.StdACROSACROS + Ye FilterACROS + R FilterACROS + G FilterBlack & WhiteBlack & White + Ye FilterBlack & White + R FilterBlack & White + G FilterSepia

Body

Body type	SLR-style mirrorless
Weather sealed	No

Sensor

Image ratio w:h	1:1, 3:2, 16:9
Effective pixels	24.3 megapixels
Sensor size	23.6 × 15.6 mm
Sensor type	CMOS
Processor	X-Processor Pro2
Color filter array	X-Trans III CMOS with primary color filter
Max resolution	6000 × 4000 px


Boosted ISO (minimum)	100
Boosted ISO (maximum)	51200
White balance presets	7
Custom white balance	Yes
Image stabilization	No
File format	JPEG (Exif 2.3), Raw (RAF format, 14-bit)

Optics & Focus

Focal length multiplier	1.5×
Lens mount	Fujifilm X
Autofocus	Contrast Detect (sensor), Phase Detect, Multi-area, Center, Selective single-point, Tracking, Single, Continuous, Touch, Face Detection, Live View
Manual focus	Yes

Screen / Viewfinder

Viewfinder type	Electronic
Viewfinder resolution	2.36 MP
Viewfinder coverage	100%
Viewfinder magnification	0.93×
Screen type	TFT LCD (RGBW)
Touch screen	Yes
Screen dots	1.04 MP
Screen size	3.0″
Articulated LCD	Tilting

Photography Features

External flash	Yes
Metering modes	multi, center-weighted, average, spot
Self-timer	Yes
Continuous drive	8 fps
Drive modes	Single, Continuous High, Continuous Low, Bracket 1, Bracket 2, Double Exposure, Panorama, Advanced Filter 1, Advanced Filter 2, Movie
Flash X sync speed	1/180 sec
Aperture priority	Yes
Built-in flash	Yes
Manual exposure mode	Yes
Shutter priority	Yes
Maximum shutter speed (electronic)	1/32000 sec
Maximum shutter speed	1/4000 sec
Minimum shutter speed	30 sec
Subject / scene modes	Unknown

Videography

Resolutions	3840 x 2160 (29.97p, 25p, 24p, 23.98p), 1920 x 1080 (59.94p, 50p, 29.97p, 25p, 24p, 23.98p), 1280 x 720 (60p, 50p, 30p, 25p, 24p)
Format	H.264
Modes	3840 × 2160 @ 30p, H.264, StandaloneFile, MOV, 100, LinearPCM; 3840 × 2160 @ 25p, H.264, StandaloneFile, MOV, 100, LinearPCM; 3840 × 2160 @ 24p, H.264, StandaloneFile, MOV, 100, LinearPCM; 3840 × 2160 @ 23.98p, H.264, StandaloneFile, MOV, 100, LinearPCM; 1920 × 1080 @ 60p, H.264, StandaloneFile, MOV, 36, LinearPCM; 1920 × 1080 @ 50p, H.264, StandaloneFile, MOV, 36, LinearPCM; 1920 × 1080 @ 30p, H.264, StandaloneFile, MOV, 36, LinearPCM; 1920 × 1080 @ 25p, H.264, StandaloneFile, MOV, 36, LinearPCM; 1920 × 1080 @ 24p, H.264, StandaloneFile, MOV, 36, LinearPCM; 1920 × 1080 @ 23.98p, H.264, StandaloneFile, MOV, 36, LinearPCM; 1280 × 720 @ 60p, H.264, StandaloneFile, MOV, 18, LinearPCM; 1280 × 720 @ 50p, H.264, StandaloneFile, MOV, 18, LinearPCM; 1280 × 720 @ 30p, H.264, StandaloneFile, MOV, 18, LinearPCM; 1280 × 720 @ 25p, H.264, StandaloneFile, MOV, 18, LinearPCM; 1280 × 720 @ 24p, H.264, StandaloneFile, MOV, 18, LinearPCM; 1280 × 720 @ 23.98p, H.264, StandaloneFile, MOV, 18, LinearPCM
Microphone	Stereo
Speaker	Mono

Storage

Storage types	SD / SDHC / SDXC (UHS-I compatible)

Connectivity

Wireless	Built-In
Remote control	Yes
USB charging	Unknown
Headphone port	No
Microphone port	Yes
HDMI	Yes
USB	USB 2.0 hi-speed (480 Mbit/sec)

Physical

Battery description	NP-W126s lithium-ion battery
Battery life (CIPA)	350
Weight (inc. batteries)	383 g
Orientation sensor	Yes
GPS	Optional
GPS notes	via smartphone
